NM-3.5T · 3.5 Ton Electric Forklift
3.5 Ton Electric Forklift
A 3,500 kg ride-on electric forklift with a maximum lift height of 6,000 mm. A heavy-duty 4-wheel electric truck for factories and logistics hubs with heavier loads and taller racking, offered with lithium-ion or lead-acid battery options.
Ask about this forklift
Share your requirement - we confirm specifications and quote manually.
Or reach us directly
- Rated capacity
- 3,500 kg
- Battery options
- Lithium-ion or lead-acid (options)
- MOQ
- 1 unit (per supplier listing)
- Lead time
- ≈15 days for 1 unit (per supplier listing)
Key Specifications
| Rated Capacity | 3,500 kg |
|---|---|
| Lift Height | Up to 6,000 mm (per supplier listing) |
| Load Center | 500 mm (per supplier listing) |
| Overall Length | 2,850 mm (shipping, per supplier listing) |
| Overall Width | 1,240 mm (shipping, per supplier listing) |
| Overall Height | 2,300 mm (shipping, per supplier listing) |
| Min. Turning Radius | 2,400 mm (per supplier listing) |
| Fork Length | 1,070 mm (per supplier listing) |
| Fork Width | 300 mm (per supplier listing) |
| Battery Type | Lithium-ion or lead-acid (options) |
| Drive Motor | AC motor (per supplier listing) |
| Tire Type | 650-10 solid (per supplier listing) |
| Operating Weight | 4,700 kg (shipping, per supplier listing) |
| Mast Type | Two-stage (per supplier listing) |
| Gradeability | 8% laden (per supplier listing) |
| Travel Speed | 14 km/h max (per supplier listing) |
| Drive Type | Ride-on, 4-wheel (per supplier listing) |
| Power Type | Electric |
Specifications are compiled from supplier listings. Any remaining details are confirmed with the factory during quotation.
Who This Forklift Suits
Factories, building-material distributors and logistics hubs in Southeast Asia that handle loads up to 3.5 tons and stack to racking up to 6,000 mm - and want electric operation instead of diesel.
Typical applications
Key Features
- 3,500 kg rated capacity for heavy industrial loads
- Maximum lift height of 6,000 mm for tall racking
- Ride-on, 4-wheel configuration with electric drive
- Lithium-ion or lead-acid battery options
- 1,070 mm forks (300 mm width, per supplier listing)
Configuration Options
Sourcing & Supply
- Manufacturer / Supplier
- Shandong Nuoman Engineering Machinery Co., Ltd.
- Supplier Type
- Manufacturer
- Manufacturing Location
- Jining, Shandong, China
- Export Capability
- Export orders supported (per supplier listing)
- OEM / Customization
- Available (customization supported)
- Certification
- Documentation available upon request
- MOQ
- 1 unit (per supplier listing)
- Lead Time
- ≈15 days for 1 unit (per supplier listing)
- Warranty
- 1 year (per supplier listing)
Sourcing details are compiled from supplier listings and verified during quotation.
Frequently Asked Questions
When should I choose 3.5 ton over 3 ton?
Choose 3.5 ton when loads regularly exceed 3 tons or when longer load centers eat into your capacity margin. Both the 3 ton and 3.5 ton models lift to 6,000 mm (per supplier listing), so the decision is mainly about load weight.
Can it stack to 6 meters?
Yes - the maximum lift height is 6,000 mm. Tell us your top beam level and pallet weight in the RFQ so we confirm the mast and capacity at height.
What battery does the 3.5 ton model need?
Battery voltage and capacity are confirmed during quotation based on your shift pattern. Lithium is recommended for heavy multi-shift use.
