NM-0.8T · 0.8 Ton Electric Forklift
800 KG Electric Forklift
An 800 kg ride-on electric forklift with a maximum lift height of 3,000 mm. A light-duty 4-wheel electric truck for small warehouses and workshops that need more margin than manual handling equipment, with lithium-ion or lead-acid battery options.
Ask about this forklift
Share your requirement - we confirm specifications and quote manually.
Or reach us directly
- Rated capacity
- 800 kg
- Battery options
- Lithium-ion or lead-acid (options)
- MOQ
- 1 unit (per supplier listing)
- Lead time
- ≈15 days for 1 unit (per supplier listing)
Key Specifications
| Rated Capacity | 800 kg |
|---|---|
| Lift Height | Up to 3,000 mm (per supplier listing; higher masts optional) |
| Load Center | 500 mm (per supplier listing) |
| Overall Length | 2,100 mm (shipping, per supplier listing) |
| Overall Width | 1,120 mm (shipping, per supplier listing) |
| Overall Height | 2,150 mm (shipping, per supplier listing) |
| Min. Turning Radius | 2,400 mm (per supplier listing) |
| Fork Length | 1,070 mm (per supplier listing) |
| Fork Width | 300 mm (per supplier listing) |
| Battery Type | Lithium-ion or lead-acid (options) |
| Drive Motor | AC motor (per supplier listing) |
| Tire Type | 650-10 solid (per supplier listing) |
| Operating Weight | 1,550 kg (shipping, per supplier listing) |
| Mast Type | Two-stage (per supplier listing) |
| Gradeability | 8% laden (per supplier listing) |
| Travel Speed | 14 km/h max (per supplier listing) |
| Drive Type | Ride-on, 4-wheel (per supplier listing) |
| Power Type | Electric |
Specifications are compiled from supplier listings. Any remaining details are confirmed with the factory during quotation.
Who This Forklift Suits
Small warehouses, workshops and e-commerce stockrooms in Southeast Asia handling palletized goods up to 800 kg - a step up from manual equipment with stacking to 3,000 mm.
Typical applications
Key Features
- 800 kg rated capacity for light pallet work
- Maximum lift height of 3,000 mm for low racking and mezzanine storage
- Ride-on, 4-wheel configuration with electric drive
- Lithium-ion or lead-acid battery options
- 1,070 mm forks (300 mm width, per supplier listing)
Configuration Options
Sourcing & Supply
- Manufacturer / Supplier
- Shandong Nuoman Engineering Machinery Co., Ltd.
- Supplier Type
- Manufacturer
- Manufacturing Location
- Jining, Shandong, China
- Export Capability
- Export orders supported (per supplier listing)
- OEM / Customization
- Available (customization supported)
- Certification
- Documentation available upon request
- MOQ
- 1 unit (per supplier listing)
- Lead Time
- ≈15 days for 1 unit (per supplier listing)
- Warranty
- 1 year (per supplier listing)
Sourcing details are compiled from supplier listings and verified during quotation.
Frequently Asked Questions
Should I choose 800 kg or 1 ton?
If your regular loads stay under 700-800 kg, the 800 kg model covers them. If loads occasionally approach 1 ton, the 1 ton model gives a safer margin and a taller 4,000 mm maximum lift height.
Is this model suitable for e-commerce stockrooms?
Yes. The 800 kg capacity covers typical e-commerce parcel pallets, and the ride-on 4-wheel format handles continuous light duty in stockrooms and small fulfillment areas.
What battery should I choose?
Both lithium-ion and lead-acid options are available. Battery voltage, capacity and charging time are confirmed with the manufacturer during quotation based on your shift pattern.
Related Products
1 Ton · NM-1T
1 Ton Electric Forklift
A 1,000 kg ride-on electric forklift with a maximum lift height of 4,000 mm. A compact 4-wheel electric truck for small warehouses, workshops and retail stockrooms handling standard 1 ton pallets, with lithium-ion or lead-acid battery options.
View specifications →
1.5 Ton · NM-1.5T
1.5 Ton Electric Forklift
A 1,500 kg ride-on electric forklift with a maximum lift height of 6,000 mm. A compact 4-wheel electric truck that steps up from the 1 ton model for warehouses, factories and e-commerce operations with mixed pallet weights.
View specifications →
2 Ton · NM-2T
2 Ton Electric Forklift
A 2,000 kg ride-on electric forklift with a maximum lift height of 6,000 mm. The general-purpose capacity of the range - a 4-wheel electric truck for warehouses, factories and logistics operations handling standard 1 - 2 ton pallets, with lithium-ion or lead-acid battery options.
View specifications →Compare other capacities: 1 Ton · 1.5 Ton · 2 Ton · 2.5 Ton · 3 Ton · 3.5 Ton
Related Guides
Buying Your First Forklift: A Small Business Guide to Mini Electric Forklifts
Outgrown the hand pallet jack? Here's what a mini electric forklift (800kg–1.5 ton) actually covers, what it doesn't, how much it really costs to own one, and why most small businesses in Southeast Asia are buying electric instead of diesel.
What Is a Small Electric Forklift? (And Why It's Probably What You Need)
The plain truth about small electric forklifts: what they are, what they aren't, who actually needs one, and which capacity class fits your warehouse, shop floor or loading dock.
Get a quotation for the 800 KG Electric Forklift
Tell us your lift height, battery preference and destination port - we will confirm the full specification and return a matched quotation.
